The Brickell, Gordon, McCurley and Wilson (BGMW) Method for Fast Exponentiation with Precomputed Values
I love reading classic patents, and [here] is a classic that was submitted by Brickwell, Gordon, and McCurley. It was patent number 5,299,262 and was assigned to the United States of America:
As is common, the authors published the work later as a research paper [1]:
Square and multiply method
The standard way to produce an exponent is to use the square and multiply method (SMQ), and where we take a maximum of (log_2 N)-2 operations, and where N is the largest value we can have for our power value. So for a 256-bit exponentation value we would have up to 254 operations.
So 5⁴ (where 4 is the exponent) becomes:
5² = 25
25²= 625
If we can to multiply 5⁸ that is 5² squared to give 5⁴, and then if we square again we get 5⁸. It has thus taken us three operations to find a power of 8. For 5⁶⁴, we will need six operations:
5²→5⁴→5⁸→5¹⁶→5³²→5⁶⁴
But lets say we want 5⁹. For this we square as we did before to give us 5⁸, and then just multiply by 5 to give 5⁹.
The basic method involves converting the exponent into bits, and then multiplying and squaring if the bit is a ‘1’ (or a power of two), or square if it is a ‘0’. In Python this becomes:
def exp_func(x, y):
exp = bin(y)
value = x
for i in range(3, len(exp)):
value = value * value
print i,":\t",value
if(exp[i:i+1]=='1'):
value = value*x
print i,"*:\t",value
return value
So, with an exponent is 12 we have a binary value of 1100. We ignore the first bit, and start on the ‘1’ (1100) , where we multiply and square. Next we have a ‘0’ (1100), so we just square, and finally a ‘0’ (1100), so we again just square. If we want to raise 5¹², we square(5²) and multiply (5³), next square (5⁶), next square (5¹²) [demo]:
Binary value of b is: 0b1100
Bit Result
2 : 25 (square)
2 : 125 (multiply)
3 : 15625 (square)
4 : 244140625 (square)
Result: 244140625
If we try 5¹²⁸ we get:
We will calculate a^b
a= 5
b= 128
==== Calculation ====
Binary value of b is: 0b10000000
Bit Result
2 : 25 (square)
3 : 625 (square)
4 : 390625 (square)
5 : 152587890625 (square)
6 : 23283064365386962890625 (square)
7 : 542101086242752217003726400434970855712890625 (square)
8 : 293873587705571876992184134305561419454666389193021880377187926569604314863681793212890625 (square)
Result: 293873587705571876992184134305561419454666389193021880377187926569604314863681793212890625
BGMW Method
With the Brickell, Gordon, McCurley and Wilson (BGMW) method we can set up fast exponentiation using precomputed values. With this, we have the form of g^n and where we store the pre-computed values of g^{x0}, g^{x1} … g^{xm−1}. We find the decomposition of n with:
and where 0≤a_i≤h, for 0≤i≤m. It is then possible to compute:
and where:
The core application of this is where we have a fixed value of g, and can thus build up pre-computed values for g^n. Overall this will save time in computing the value. The coding is here:
import sys
x = [1,3,5,9]
ai=[4,0,4,1]
h=4
g=3
p=2**255-19
if (len(sys.argv)>1):
g=int(sys.argv[1])
if (len(sys.argv)>2):
ai=eval("["+sys.argv[2]+"]")
if (len(sys.argv)>3):
x=eval("["+sys.argv[3]+"]")
h=max(ai)
xi =[0]*len(x)
for i in range(len(x)):
xi[i]=pow(g,x[i])
print (f"g={g}")
print (f"a_i={ai}")
print (f"x_i={x}")
print (f"\nh={h}")
print(f"p={p}")
n=0
b=1
a=1
for i in range(len(x)):
n=n+ai[i]*x[i]
for d in range(h,0,-1):
for i in range(len(ai)):
if (ai[i]==d):
b=b*pow(g,x[i],p)
a=(a*b) % p
print (f"\n{g}^{n} mod p={a}")
print ("\nLet's check with pow(g,n,p)")
res=pow(g,n,p)
print (f"{g}^{n} mod p={res}")
A sample run is:
g=3
a_i=[4, 0, 4, 1]
x_i=[1, 3, 5, 9]
h=4
p=57896044618658097711785492504343953926634992332820282019728792003956564819949
3^33 mod p=5559060566555523
Let's check with pow(g,n,p)
3^33 mod p=5559060566555523
In this case we have:
n=4×1+0×3+4×5+1×9=33
We then get 3^{33}. The coding is here:
and a demo:
With the Brickell, Gordon, McCurley and Wilson (BGMW) method we can setup a fast exponentiation using precomputed…asecuritysite.com
Conclusions
If you are interested in other patents, please try here:
We have had three highly successful Cybersecurity spin-out companies, and now setting up our fourth with MemCrypt. In…medium.com
and:
As a researcher it is not only important to know where we are and where we are going, but it is just as important to…medium.com
References
[1] Brickell, E. F., Gordon, D. M., McCurley, K. S., & Wilson, D. B. (1992, May). Fast exponentiation with precomputation. In Workshop on the Theory and Application of of Cryptographic Techniques (pp. 200–207). Springer, Berlin, Heidelberg.[here].
